FiberPlex FP2008E Managed Industrial Gigabit Ethernet Switch 10 Port, 8 Copper 10/100/1000 + 2 x GigE SFP; industrial packaging

FiberPlex FP2008E Managed Industrial Gigabit Ethernet Switch 10 Port, 8 Copper 10/100/1000 + 2 x GigE SFP; industrial packaging

Category: Tags: , , , ,
Brand: Fiberplex

$1,815.00

Description

Patton’s FP2008E Managed Industrial Gigabit Ethernet Switch supports industrial applications requiring high bandwidth or high density connections. The FP2008E is a fully manageable Layer 2 Ethernet switch, pre-loaded with a user-friendly web management console design. Ring network redundancy is provided by MSTP/RSTP and open standard ITU-T G.8032 ERPS (Ethernet Ring Protection Switch) protocol which has a < 50ms network recovery time. Advanced L2 network filtering and prioritization include IGMP, VLAN, QoS/CoS/ToS. Efficient monitoring and security can be achieved through SNMPv1/v2/v3, RMON, port mirroring, 802.1x, HTTPS, SSH/SSL.

The FP2008E is housed in a sturdy IP30-rated DIN-rail enclosure with wall mount options. The physical layer interfaces include 8 RJ45 10/100/1000 Ethernet ports and two Gigabit SFP+ slots that can be used for fiber trunk connections. To ensure operation in harsh environments, the FP2008E provides additional EFT and ESD protection that prevent unregulated voltage or harmful transients, and has an operating temperature rating of -40 to 167°F (-40 to 75°C).

SFP Ordering Information
Fiber SFP Data Module
Copper SFP Modules

Applications

FiberPlex™ 2008E application diagram

  • System Interface/Performance – Supports auto MDI/MDI-X function
    10 ports include 8 10/100/1000TX RJ45 ports and 2 100/1000 SFP cages
    Network redundancy features:

    • Spanning Tree: RSTP/MSTP
    • Ring Protection: G.8032 ERPS

    Traffic prioritization features:

    • IEEE802.1Q VLAN
    • IEEE802.1p; CoS/ToS

    IGMPv1/v2 up to 256 groups
    8K MAC address table
    9.6K Jumbo frame supports
    ESD protection: 6,000 VDC

  • Power Input – Redundant power input design: 12–48 VDC
    Built-in relay output for power failure detection
    Surge protection: 2,000 VDC support
  • Extended Operating Temperature – -40 to 167°F (-40 to 75°C)
  • Case/Installation – IP30 rugged metal case
    DIN-rail and wall mount support
Copper Ethernet Port 8 x RJ45 10/100/1000TX auto MDI/MDI-X
Fiber Ethernet Port 2 x GigE SFP cages
Wavelength: Refer to patton.com/SFP-OC
RS232 Console Port 1 x RJ45, 115.2kbps, 8, N, 1
USB2.0 Port Configuration Backup
Switching Properties Backplane (Switching Fabric): 10 Gbps
Processing Type: Store and Forward
Transfer Rate:

  • 14,880pps for 10Base-T Ethernet
  • 148,800pps for 100Base-T Fast Ethernet
  • 1,488,000pps for Gigabit Ethernet

Jumbo Frame: 9.6 Kbytes
MAC Table Size: 8K
Packet Buffer: 4 Mbits
VLAN Group: 1–4,094
IGMP Group: Up to 256 groups
Networking Standards IEEE 802.3 10Tx
Ethernet IEEE 802.3u 100Tx Fast Ethernet
IEEE 802.3ab 1000Tx Gigabit Ethernet
IEEE 802.3z Gigabit Fiber
IEEE 802.3x Flow Control for Full Duplex
IEEE 802.3ad for Port Trunk with LACP
IEEE 802.1d STP (Spanning Tree Protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
ITU-T G.8032/Y.1344 ERPS (Ethernet Ring Protection Switch) Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1x for Network Authentication
IEEE 802.1p QoS/CoS Protocol for Traffic Prioritization
Additional Standards IGMPv1/v2, SNMPv1/v2c/v3, TFTP, SNTP, SMTP, RMON, HTTP, HTTPS, Telnet, Syslog, DHCP Option 66/67/82, SSH/SSL, Modbus/TCP, LLDP, IPv4/IPv6
Power Power Consumption: 15 Watts
Input Voltage: 12–48 VDC
Redundant Input (with 1 removable 6-contact terminal block) 100–240 VAC adapter (optional)
Protection Reverse Polarity
Overload Current
CPU Watchdog
Temperature Operating: -40 to 167°F (-40 to 75°C)
Storage: -40 to 185°F (-40 to 85°C)
Ambient Relative Humidity 5 to 95%, (non-condensing
Housing Metal, IP30 protection, DIN-Rail Mounting (wall mounting bracket is also included)
Dimensions 1.81W x 3.89D x 5.59H in. (46W x 99D x 142H mm)
Weight Unit Weight: 2.5 lbs (1.1 kg)
Shipping Weight: 3.0 lbs (1.4 kg)
Certifications FCC, CE, UL 61010-1
UL 61010-2-201 Class 1 Div 2
EMI FCC Class A
EMS IEC61000-4-2, 4-3, 4-4, 4-5, 4-6, 4-8
IEC61000-6-2, 6-4
Free fall / Shock / Vibration IEC60068-2-32 / IEC60068-2-27 / IEC60068- 2-6



# Model # Description Availability
1 FP2008E/2SFP/DC Managed Industrial Gigabit Ethernet Switch; 8 x 10/100/1000; 2 x GigE SFP; -40 to 75C; 12-48 VDC input General Availability
