DrayTek Vigor 2830Vn-plus Wireless Gigabit LAN/WAN ADSL2+ Firewall

DrayTek Vigor 2830Vn-plus Dual Band Wireless 802.11n Gigabit WAN LAN ADSL2+ Modem Router Security Firewall with VoIP

Future Proof Network Connectivity
DrayTek Vigor 2830Vn-plus Gigabit WAN LAN ADSL2+ Security Firewall with Gigabit WAN Ports, built-in 4 Port Gigabit Giga LAN switch, Dual Band selectable 2.4 or 5 GHz frequency 802.11n WLAN, VoIP, and USB Port for Network FTP, Print Server, or use as a 3rd WAN Port for 3.5G / 4G* Mobile Broadband Connectivity.

DrayTek's Vigor2830 Gigabit LAN WAN ADSL2/2+ Security Firewall series includes the DrayTek Vigor 2830, DrayTek Vigor 2830n-Plus, and the Vigor2830Vn-plus all are embedded with one (1) ADSL2/2+ WAN port, one (1) Giga Ethernet WAN port, four (4) Port Gigabit LAN Switch and 1 USB port that supports 3.5G USB modem that can be used a 3rd WAN port. Additional uses for the USB port are Printer sharing, Data / File sharing (using a USB Storage device).

The Draytek Vigor 2830 series provides you with future proof connection choices for your current and next generation network (NGN) infrastructure.

The DrayTek Vigor 2830Vn-plus state-of-art routing features, VPN, Security, VoIP, QoS, Dual Band 2.4/5GHz Configurable Access Point, 3.5G USB Modem support and Gigabit LAN WAN provides superior integrated benefits for Network Integrators, home networks and small offices.

The Vigor2830Vn-plus Flexible WAN interface enables load balancing, backup and bandwidth management.
The 2nd Gigabit Ethernet WAN interface of the Vigor2830 series can be used to connect to a 2nd modem from your current or another ISP and the connection type can be ADSL/Cable/VDSL2/or Ethernet FTTx modem.
Need even More Bandwidth? No problem! The USB port can be used as the 3rd WAN interface via a USB 3.5G modem (requires a mobile broadband account). The three (3) WAN interfaces can do load-balancing to facilitate bandwidth usage. Moreover, they can do failover and backup during downtime. If you have different ISP accounts (i.e.; one from your local ISP, another from your local cable company, and a third from a Mobil Broadband carrier) providing Internet service to all three WAN interfaces, failover can be completely worry-free; even if one or two ISPs’ service temporarily goes down.

DrayTeks' Vigor 2830 series embedded with tag-based multi-subnet function can satisfy the security needs of distinguishing extranet and corporate intranet by Routine/NAT mode or multiple workgroups by different subnets. Besides, it can configure different subnets to each application, such as VoIP and IPTV to prevent interference.

USB port for 3.5G, FTP and Print Server
Not only for 3.5G/4G mobile broadband, USB port also supports printer servers and allows the connection of a USB disk or hard drive for FTP file transfer through the Internet or local networks. The network administrator can set username/password and directory/file access privilege for individual users.

Vigor2830Vn plus Front Panel View / Gigabit WAN/LAN


Secure Networking
By adopting a hardware-based VPN platform and hardware encryption of AES/DES/3DS, the router significantly increases the performance of VPN and offers several protocols (such as IPSec/PPTP/L2TP) with up to 32 VPN tunnels. The object-based design used in SPI (Stateful Packet Inspection) firewall allows users to set firewall policies with ease. The Object-based firewall is flexible and keeps your network be safe. DoS/DDoS prevention and URL/Web content filter strengthen the security outside and control inside. The enterprise-level CSM (Content Security Management) enables users to control and manage IM (Instant Messenger) and P2P (Peer-to-Peer) applications more efficiently. The CSM can be used to prevent inappropriate content from distracting employees and impeding productivity. Furthermore, the CSM can keep your office, and networks threat-free and available.

Vigor2830 series supports DrayTeks' ' SmartMonitor ' Network Activity Management Application (monitoring of up to 30 users), which captures actual live data of activities on your managed network. Activities such as the content of MSN entering to or out of your network. You can also track file downloads/uploads or view statistics on data-type activities to monitor what corporate related information may have been released accidentally or intentionally.

DrayTek Vigor 2830Vn-plus Comprehensive Multi-Site Communications

Easy-to-Manage and Configurable WLAN
In addition to the encryption methods of WEP/WPA/WPA2 and MAC address control, the DrayTek Vigor 2830Vn-plus also offers wireless LAN isolation, Wireless VLAN and 802.1X authentication. The embedded WDS (Wireless Distribution System) can help users to easily extend wireless coverage. Moreover, the wireless rate-control can be adjusted for each wireless station. The WMM (Wi-Fi multimedia) provides the priority of voice, video and audio applications in a Wi-Fi network and lowers priority of other network traffic, which is not time-critical.

Wireless Dual Band
Selectable 5G or 2.4GHz configuration of Vigor2830n-plus and Vigor2830Vn-plus provides extra choices for SMBs to build their WLAN network. In addition to the common 2.4GHz frequency, SMB can configure WLAN network on the less congested 5GHz spectrum.

Integration of Telephony
The DrayTek Vigor2830Vn-plus provides twin analog phone pots and one line line port. It supports multiple SIP Registrars with highly flexible configuration and call handing options. You can connect your analog line ( PSTN / POTS* ) to the Line port of Vigor2830Vn-plus. When you enable VoIP facility, you still can access fixed line (analog line) to make calls by dialing # 0. The telephone connected to Line port and two FXS ports can be used for both analog calls and VoIP calls because the incoming calls are automatically switched through to your telephone(s) (either one or both). As a result, both analog telephones plugged into your Vigor 2830Vn-plus allow you to access VoIP and analogue line. Furthermore, you can set rules through "Digit Map" function about particular call destinations using either your SIP/VoIP service or the POTS line. e.g. you can route local calls via your PSTN line (if you have a free calls package) whereas international calls go via your preferred VoIP provider; there is flexibility to have several Digit Map rules.

DrayTek Vigor 2830Vn-plus Features

WAN Protocol

• ADSL2+ (WAN-1) :
  • DHCP Client
  • Static IP
  • PPPoE / PPPoA
  • BPA
• Giga Ethernet (WAN-2) :
  • DHCP Client
  • Static IP
  • PPPoE
  • PPTP
  • L2TP
  • BPA
• USB (WAN-3) :
  • PPP

Multi-WAN

• Outbound Policy-based Load-balance
• BoD (Bandwidth On Demand)
• WAN Connection Fail-over

VoIP (Voice over IP)

• Protocol: SIP, RTP/RTCP
• 12 SIP Registrars
• G.168 Line Echo-cancellation
• Automatic Gain Control
• Jitter Buffer (180ms)
• Voice Codec :
  • G.711 A/u law
  • G.723.1
  • G.726
  • G.729 A/B
  • G.722_64
  • VAD / CNG
  • iLBC*
• DTMF Tone :
  • In Band
  • Out Band (RFC-2833)
  • SIP Info
• FAX/Modem Support :
  • Tone Detection
  • G.711 Pass-through
• Supplemental Services :
  • Call Hold / Retrieve / Waiting
  • Call Waiting with Caller ID
  • Call Transfer
  • Call Forwarding (Always / Busy / No Answer)
  • Call Barring (Incoming / Outgoing)
  • DND (Do Not Disturb)
  • MWI (Message Waiting Indicator) (RFC-3842)
  • Hotline
• Dial Plan :
  • Phone Book
  • Digit Map

Wireless Access Point (n model)

• Support Dual Band 2.4/5G Configurable (Configurable/Not Simultaneous)
• IEEE802.11n Compliant
• Wireless Client List
• Wireless LAN Isolation
• 64 / 128 bit WEP
• WPA / WPA2
• Hidden SSID
• WPS
• Mac Address Access Control
• Access Point Discovery
• WDS (Wireless Distribution System)
• Multiple SSID
• Wireless Rate-control
• IEEE802.11e: WMM (Wi-Fi Multimedia)
• SSID VLAN Grouping with LAN Port

VPN

• Up to 32 VPN Tunnels
• Protocol : PPTP, IPSec, L2TP, L2TP over IPSec
• Encryption : MPPE and Hardware-based AES/DES/3DES
• Authentication : MD5, SHA-1
• IKE Authentication : Pre-shared Key and Digital Signature (X.509)
• LAN-to-LAN , Teleworker-to-LAN
• DHCP over IPSec
• IPSec NAT-traversal (NAT-T)
• Dead Peer Detection (DPD)
• VPN Pass-through
• VPN Wizard
• mOTP

Firewall

• Multi-NAT / DMZ Host / Port-redirection / Open Port
• Object-based Firewall
• MAC Address Filter
• SPI (Stateful Packet Inspection) (Flow Track)
• DoS / DDoS Prevention
• IP address Anti-spoofing
• E-Mail Alert and Logging via Syslog
• Bind IP to MAC Address
• Time Schedule Control
• Firewall v3

Bandwidth Management

• QoS :
  • Guarantee Bandwidth for VoIP
  • Class-based Bandwidth Guarantee by User-Defined Traffic Categories
  • DiffServ Code Point Classifying
  • 4-level Priority for Each Direction (Inbound / Outbound)
  • Bandwidth Borrowed
• Bandwidth / Session limitation
• Layer-2 (802.1p) and Layer-3 (TOS/DSCP) QoS Mapping

CSM (Content Security Management)

• IM/P2P Application V3 (App Enforcement)
• GlobalView Web Content Filter (Powered by )
• User Management
• URL Content Filter :
  • URL Keyword Blocking (Whitelist and Blacklist)
  • Java Applet, Cookies, Active X, Compressed, Executable, Multimedia File Blocking
  • Excepting Subnets
  • Time Schedule Control

Network Feature

• Packet Forwarding Acceleration
• DHCP Client / Relay / Server
• IGMP Version 2 and Version 3
• Dynamic DNS
• NTP Client
• Call Scheduling
• RADIUS Client
• DNS Cache/Proxy
• UPnP 30 sessions
• Multiple Subnets
• VLAN Tagging (802.1q) on LAN
• Routing Protocol :
  • Static Routing
  • RIP V2

USB

• 3.5G/4G * as WAN-3
• Printer Sharing
• File System :
  • Support FAT32/FAT16 File System
  • Support FTP Function for File Sharing

Network Management

• Web-based User Interface (HTTP / HTTPS)
• Quick Start Wizard
• CLI (Command Line Interface , Telnet / SSH)
• Administration Access Control
• Configuration Backup / Restore
• Built-in Diagnostic Function
• Firmware Upgrade via TFTP / FTP / HTTP / TR-069
• Logging via Syslog
• SNMP Management MIB-II
• Management Session Time Out
• 2-level Management (Admin/User Mode)
• TR-069
• TR-104

Switch

• Port-based VLAN
• Triple-Play Application
• IGMP Snooping
• Tag-based (802.1q) VLAN
• Layer-2 (802.1p) QoS

ORDERING INFORMATION
